Pixhawk 6C Flight Controller – Reliable and Compact for Advanced Drone Systems

Description

The Pixhawk® 6C is the latest addition to the Pixhawk® flight controller lineup, built on the FMUv6C Open Standard and Connector Standard, with PX4 Autopilot® pre-installed. Powered by an STM32H743 microcontroller featuring an Arm® Cortex®-M7 core, it offers 480 MHz processing speed, 2MB flash memory, and 1MB RAM. High-performance, low-noise IMUs and a vibration isolation system ensure accurate readings and enhanced flight performance. Ideal for academic and commercial autonomous vehicle applications, it supports complex algorithm development with reliability and flexibility.

Key Design Points:

• High performance H7 Processor with clock speed up to 480 MHz
• New cost-effective design with low-profile form factor
• Redundant inertial measurement unit (IMU) from Bosch® & InvenSense®
• Newly designed integrated vibration isolation system to filter out high frequency vibration and reduce noise to ensure accurate readings
• IMUs are temperature-controlled by onboard heating resistors, allowing optimum working temperature of IMUs

Specification

Processors & Sensors

• FMU Processor: STM32H743
  • 32 Bit Arm® Cortex®-M7, 480MHz, 2MB memory, 1MB SRAM
• IO Processor: STM32F103
  • 32 Bit Arm® Cortex®-M3, 72MHz, 64KB SRAM
• On-board sensors
  • Accel/Gyro: ICM-42688-P
  • Accel/Gyro: BMI055
  • Mag: IST8310
  • Barometer: MS5611

Electrical data

• Voltage Ratings:
  • Max input voltage: 6V
  • USB Power Input: 4.75~5.25V
  • Servo Rail Input: 0~36V
• Current Ratings:
  • Telem1 Max output current limiter: 1.5A
  • All other port combined output current limiter: 1.5A

Mechanical data

• Dimensions: 84.8 * 44 * 12.4 mm
• Weight (Aluminum Case) : 59.3g
• Weight (Plastic Case) : 34.6g
